Zebra FS42 Fixed bar code reader 1D/2D CMOS Black, Green

FS42 Fixed Industrial Auto Focus Scanner: Standard Range, 2.3 MP, Fast 2D Barcode Decoder, Ethernet with POE, Serial, USB and Industrial Protocols, Red Illumination, No Filter - Worldwide

Description

FS42 Fixed Industrial Scanner

Built for High-Speed Data Capture and Deep Learning Applications
Building off the all-around performance and flexibility of the FS40, the FS42 is optimized for resource-intensive tasks like deep learning-based OCR applications and high-speed scanning when speed is paramount. With increased on-board memory and a neural processing unit (NPU) for accelerated data processing, the FS42 also offers a seamless upgrade path to more complex machine vision applications.

Powerful Scanning Performance
From fast moving conveyors and scan tunnels to forklift and dock door scanning, the FS42 delivers outstanding performance and versatility for demanding scanning applications. Get first-time every time capture of 1D/2D barcodes and direct part marks with PRZM Intelligent Imaging.

Scalable Automation Options
Purpose-built with a powerful new processor and increased on-board memory, the FS42 supports ever-more challenging machine vision applications that demand significant processing power. This device lets you confidently power applications today and be ready to meet future requirements.

Deep-Learning-Driven Performance Enhancements
The FS42 excels at applications like deep-learning-based OCR (DL-OCR), thanks to its enhanced processing powers. Upgrading its software license further enables advanced machine vision applications such as anomaly detection, marking a significant performance leap in industrial automation.

Specifications

Scanning
Type Fixed bar code reader
Linear (1D) barcodes supported Codabar, Code 39, Code 93, MSI-Plessey, Plessey, Standard 2 of 5
2D (matrix & stacked) barcodes supported Aztec Code, Data Matrix, Dot Code A, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Sensor type CMOS
Scanner type 1D/2D
Read rate (max) 60 reads/s
Optical sensor resolution (W x H) 1920 x 1200 pixels
Ports & interfaces
Connectivity technology Wired
Ethernet LAN data rates 10,100,1000 Mbit/s
Standard interfaces USB
Performance
LED indicators Yes
International Protection (IP) code IP65, IP67
Product colour Black, Green
Design
Type Fixed bar code reader
LED indicators Yes
International Protection (IP) code IP65, IP67
Product colour Black, Green
Power
Power source type PoE, USB
Weight & dimensions
Width 64 mm
Depth 91.4 mm
Height 54 mm
Weight 400 g
Technical details
Type Fixed bar code reader
LED indicators Yes
International Protection (IP) code IP65, IP67
Product colour Black, Green
Packaging data
External power adapter Yes
Network
Ethernet LAN data rates 10,100,1000 Mbit/s
Operational conditions
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Packaging content
External power adapter Yes

  Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.   Note: Products do not come with cables or accessories unless specifically stated.
