TSC

TSC MB341T label printer Direct thermal / Thermal transfer 300 x 300 DPI 228.6 mm/sec Wired & Wireless Ethernet LAN Wi-Fi Bluetooth

SKU MB341T-A001-0202
£1,058.56
£657.61
£1,058.56
£657.61
In stock 73 left

TSC

TSC MB341T label printer Direct thermal / Thermal transfer 300 x 300 DPI 228.6 mm/sec Wired & Wireless Ethernet LAN Wi-Fi Bluetooth

SKU MB341T-A001-0202
£1,058.56
£657.61
TSC MB341T label printer Direct thermal / Thermal transfer 300 x 300 DPI 228.6 mm/sec Wired & Wireless Ethernet LAN Wi-Fi Bluetooth

MB341T 300dpi, 3.5" Touch LCD, DRAM 256MB/Flash 256MB, USB+RS-232+Ethernet+USB Host+RTC, Wi-Fi Ready, EU & UK (EMEA)

Description

Optimised Space Efficiency

The bifold door reduces space usage by 24%, streamlining media, ribbon replacement, and cleaning for efficient operations in limited space. (Available for the MB241 Series)

High-Quality Printing Assurance

- A robust all-metal print mechanism on a metal frame guarantees printing stability and printer longevity.
- Equipped with features to adjust the multi-point thermal printhead (TPH) pressure and heat line, it ensures consistent, high-quality printing.

Fits Diverse Applications Requirements

- Options: a cutter, an internal rewinder, and peel-off, linerless and RFID upgrade kits enhance printer versatility and cater to diverse needs.
- Connectivity options like MFi Bluetooth 5.0, Wi-Fi Bluetooth combo, and Bluetooth 5.0 offer flexibility for diverse applications.
- RFID functionality: Encode During Print feature for enhanced efficiency, support for diverse tags (including on-metal labels up to 1.65 mm) verified by our RFID Label and Validation Lab, and auto calibration for easy setup. (Available for the MB241 Series)

TSC Sense Care Smart Monitoring

- TSC Sense Care prevents downtime by monitoring printhead health with self-diagnostic TPH Care, printhead mileage, and cutter counts.
- Collected data can integrate with SOTI Connect and TSC Console for remote management and reporting.

Software Capabilities Harmonize Operations

- Auto-switch printer language emulation simplifies printer fleet migration and upgrades without changing print commands and label templates.
- TSC Standalone Creator generates printer LCD UI for quick template access and TSCPRTGo turns a mobile device into an extended display for mobile printing.
- SOTI Connect and TSC Console manage printer fleets, enabling swift deployment, configuration, and updates remotely.
- The Internal Embedded Webpage enables IT to remotely configure, troubleshoot, and oversee any specific printer in the field. (Available for the MB241 Series)

Commitment to Sustainability

- 100% recyclable packaging reduces environmental waste.
- 100% recyclable printer casing with over 90% recyclable printer components.
- The optional linerless kit offers a sustainable solution for greener label printing.

Note: In alignment with our sustainability vision, we are beginning to implement eco-friendly packaging and product design concepts, starting with the new generation MB241 Series.

Specifications

Print quality
Maximum resolution 300 x 300 DPI
Maximum printing width 10.6 cm
Maximum print height 1.14 cm
Printing
Colour No
Print speed 228.6 mm/sec
Maximum resolution 300 x 300 DPI
Maximum printing width 10.6 cm
Maximum print height 1.14 cm
Print technology Direct thermal / Thermal transfer
Number of printable dots 12 dot
Display
Display diagonal 8.89 cm (3.5")
Colour display Yes
Display LCD
Network
Wi-Fi Yes
Ethernet LAN Yes
Memory
Internal memory 256 MB
Flash memory 256 MB
Paper handling
Ribbon width 11 cm
Ribbon length 450 m
Maximum media length 12 cm
Ports & interfaces
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
RS-232 ports 1
Connectivity technology Wired & Wireless
Bluetooth version 5.0
Bluetooth Yes
Wi-Fi Yes
Ethernet LAN Yes
USB port Yes
Performance
Built-in barcodes 1D, 2D, AZTECCODE, China post, Code 11, Code 128 (A/B/C), Code 39, Code 93, Code-128 Codabar Library, Code128UCC, Datamatrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MSI, MaxiCode, PDF417, POSTNET, Plessey, QR Code, TLC39, UPC-A, UPC-E
Ribbon width 11 cm
Ribbon length 450 m
Internal memory 256 MB
Flash memory 256 MB
Built-in RFID module Yes
Built-in processor Yes
Page description languages DPL, EPL, TSPL, TSPL-EZ, ZPL, ZPL II
Tape end detection Yes
Open cover detection Yes
Design
Display diagonal 8.89 cm (3.5")
Colour display Yes
Display LCD
Product colour Black
Control type Buttons, Touch
Built-in display Yes
Power
AC adapter output voltage 24 V
AC adapter output current 3.75 A
Power consumption (printing) 90 W
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Technical details
Product colour Black
Built-in barcodes 1D, 2D, AZTECCODE, China post, Code 11, Code 128 (A/B/C), Code 39, Code 93, Code-128 Codabar Library, Code128UCC, Datamatrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MSI, MaxiCode, PDF417, POSTNET, Plessey, QR Code, TLC39, UPC-A, UPC-E
Ribbon width 11 cm
Ribbon length 450 m
Built-in RFID module Yes
Warranty period 2 year(s)
Compliance certificates BIS, BSMI, CB, CCC, CE, EAC, Federal Communications Commission (FCC), Industry Canada (IC), KC, Norma Oficial Mexicana (NOM), RCM, TÜV mark, UKCA, VCCI, cTUVus
Processor
Built-in processor Yes
Operational conditions
Storage temperature (T-T) 10 - 90 °C
Storage relative humidity (H-H) 25 - 85%
Operating temperature (T-T) -40 - 60 °C
Operating relative humidity (H-H) 0 - 45%
Weight & dimensions
Width 248 mm
Depth 436 mm
Height 274 mm
Weight 9.1 kg
Packaging content
Cables included AC, USB
Other features
Warranty period 2 year(s)
