TSC

TSC DH240T label printer Direct thermal 203 x 203 DPI 203 mm/sec Wired & Wireless Ethernet LAN Wi-Fi Bluetooth

SKU DH240-A001-0002
£316.77
£316.77
In stock 44 left

TSC

TSC DH240T label printer Direct thermal 203 x 203 DPI 203 mm/sec Wired & Wireless Ethernet LAN Wi-Fi Bluetooth

SKU DH240-A001-0002
£316.77
TSC DH240T label printer Direct thermal 203 x 203 DPI 203 mm/sec Wired & Wireless Ethernet LAN Wi-Fi Bluetooth

Direct Thermal, 203 dpi, Color Touch LCD DRAM 128MB/Flash 128MB, USB + RS-232 + Ethernet + USB Host + RTC + Buzzer, EU

Description

The 4-inch DH Series Desktop Barcode Printers are versatile and flexible for diverse printing requirements. This series’ versatility enables printing a wide range of difficult labels, including thick, tiny, and long labels and certain types of vertical market labels.

Our printer language emulation makes the DH Series plug-and-play. Its firmware automatically identifies major printer languages and begins printing immediately without changing label templates. The DH Series minimises downtime during daily operations through comprehensive printer management tools (Internal Embedded Webpage, virtual control panel, TSC Console, and SOTI Connect), printer shutdown prevention, and supports network security configurations to manage printers efficiently.

The DH Series scales up applications with a wide media width, high-precision printing, and several addable future-proof options. This empowers businesses to adapt to changing requirements for present and future operations. The eco-friendly printer features 100% recyclable packaging and plastic printer casing. Over 90% of printer components are recyclable at the printer’s end-of-life, reducing environmental impact.

Specifications

Print quality
Maximum resolution 203 x 203 DPI
Maximum printing width 10.8 cm
Printing
Print speed 203 mm/sec
Maximum resolution 203 x 203 DPI
Maximum printing width 10.8 cm
Print technology Direct thermal
Number of printable dots 8 dot
Display
Display diagonal 10.2 cm (4")
Colour display Yes
Display resolution 480 x 320 pixels
Display LCD
Network
Wi-Fi Yes
Ethernet LAN Yes
Memory
Internal memory 128 MB
Flash memory 128 MB
Paper handling
Media thickness 0.06 - 0.19 mm
Maximum roll diameter 3.81 cm
Maximum media length 12 cm
Maximum label length 25.4 m
Ports & interfaces
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
RS-232 ports 1
Connectivity technology Wired & Wireless
Bluetooth version 5.0
Bluetooth Yes
Wi-Fi Yes
Ethernet LAN Yes
USB port Yes
Performance
Built-in barcodes 1D, 2D, AZTECCODE, CODABAR (NW-7), China post, Codablock F, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Code-128 Codabar Library, Code128UCC, Datamatrix, Deutsche Post Identcode, Deutsche Post Leitcode, EAN128, EAN13, EAN14, EAN8, GS1 DataBar, ITF-14, Interleaved 2/5, LOGMARS, MSI, MaxiCode, MicroPDF417, PDF417, Planet, POSTNET, Plessey, QR Code, TELEPEN, TELEPENN, TLC39, UPC-A
Internal memory 128 MB
Flash memory 128 MB
Built-in processor Yes
Page description languages DPL, EPL, TSPL-EZ, ZPL, ZPL II
Open cover detection Yes
Design
Display diagonal 10.2 cm (4")
Colour display Yes
Display resolution 480 x 320 pixels
Display LCD
Product colour Black
Control type Buttons, Touch
Built-in display Yes
Power
AC adapter output voltage 24 V
AC adapter output current 3.75 A
Power consumption (printing) 90 W
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Technical details
Product colour Black
Built-in barcodes 1D, 2D, AZTECCODE, CODABAR (NW-7), China post, Codablock F, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Code-128 Codabar Library, Code128UCC, Datamatrix, Deutsche Post Identcode, Deutsche Post Leitcode, EAN128, EAN13, EAN14, EAN8, GS1 DataBar, ITF-14, Interleaved 2/5, LOGMARS, MSI, MaxiCode, MicroPDF417, PDF417, Planet, POSTNET, Plessey, QR Code, TELEPEN, TELEPENN, TLC39, UPC-A
Maximum label length 25.4 m
Sustainability certificates ENERGY STAR
Warranty period 3 year(s)
Compliance certificates BIS, CB, CCC, CE, China RoHS, EAC, Federal Communications Commission (FCC), Industry Canada (IC), KC, Norma Oficial Mexicana (NOM), RCM, REACH, RoHS, UKCA, WEEE, cTUVus
Processor
Built-in processor Yes
Operational conditions
Storage temperature (T-T) -40 - 60 °C
Storage relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 25 - 85%
Weight & dimensions
Width 208 mm
Depth 235 mm
Height 170 mm
Weight 2.1 kg
Packaging content
Cables included AC, USB
Other features
Warranty period 3 year(s)
