TSC

TSC DA320 label printer Direct thermal 300 x 300 DPI 102 mm/sec Wired Ethernet LAN

SKU 99-158A016-2102
£436.86
£318.47
£436.86
£318.47
Only 9 left

TSC

TSC DA320 label printer Direct thermal 300 x 300 DPI 102 mm/sec Wired Ethernet LAN

SKU 99-158A016-2102
£436.86
£318.47
TSC DA320 label printer Direct thermal 300 x 300 DPI 102 mm/sec Wired Ethernet LAN

DA320, RTC, EPL, ZPL, ZPLII, TSPL-EZ, USB, RS232, Ethernet

Key Features

  • Small Parcel Shipping
  • Mail Room Address and Routing Labels
  • Shipping & Receiving
  • Entertainment and Transportation Ticketing
  • Retail Point-of-Sale
  • File-Folder Labeling

Description

The DA Series of direct thermal desktop printers is ideal for a wide variety of applications including product marking, point of sale, retail, small office, shipping labels, and other labeling and tag applications at a very competitive price.

The DA Series is a perfect combination of affordability with a durable and reliable design. The DA series offers both 203 and 300 dpi print resolution with printing speeds up to a fast 6 ips. The large 60-watt power supply produces high quality printed labels, even at its fastest print speeds.

4 Models Available

The DA Series consists of four models, the DA210, DA220, DA310, and DA320, designed to provide the right fit for your application. All four models handle up to 5-inch OD rolls of direct thermal labels and can print crisp, clear barcodes, graphics and text at up to 6-inches per second.

Affordable

The low cost DA210 and DA310 models are priced right and have the features you need for most basic label printing needs using a USB 2.0 or optional Bluetooth interface.

Wireless and Hardwire Communications

Need more communications power? The DA220 and DA320 models have more memory and support nearly every major communications option including Serial RS-232, Ethernet, USB host, internal 802.11 a/b/g/n wireless, or internal Bluetooth.

Emulations and More

The DA220 and DA230 models have plenty of memory with 128 MB Flash & 64 MB SDRAM that can be used for easy storage of fonts, international character sets, and graphics. Right out of the box, it supports a fully compatible set of standard industry emulations, including Line Mode, Eltron®, Zebra® and Datamax languages, making it easy to replace old installed hardware.

Specifications

Print quality
Maximum resolution 300 x 300 DPI
Maximum printing width 10.6 cm
Printing
Colour No
Printing colours Black
Print speed 102 mm/sec
Maximum resolution 300 x 300 DPI
Maximum printing width 10.6 cm
Print technology Direct thermal
Number of printable dots 12 dot
Display
Display No
Network
Wi-Fi No
Ethernet LAN Yes
Memory
Internal memory 64 MB
Flash memory 128 MB
Paper handling
Media thickness 0.055 - 0.19 mm
Maximum media length 11.4 m
Maximum label width 11.4 cm
Ports & interfaces
USB 2.0 ports quantity 1
RS-232 ports 1
Connectivity technology Wired
Wi-Fi No
Ethernet LAN Yes
USB port Yes
Performance
Built-in barcodes 1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, QR Code, UPC-A, UPC-E
Number of fonts 8
Internal memory 64 MB
Flash memory 128 MB
Built-in processor Yes
Certification FCC Class A, CE Class A, RCM, CB, CCC, ENERGY STAR, KC, BIS, UL, EAC, RoHS, WEEE
Page description languages DPL, EPL, ZPL, ZPL II
Design
Display No
Product colour Black
Built-in display No
Certification FCC Class A, CE Class A, RCM, CB, CCC, ENERGY STAR, KC, BIS, UL, EAC, RoHS, WEEE
Power
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Technical details
Product colour Black
Built-in barcodes 1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, QR Code, UPC-A, UPC-E
Number of fonts 8
Maximum label width 11.4 cm
Processor
Built-in processor Yes
Certificates
Certification FCC Class A, CE Class A, RCM, CB, CCC, ENERGY STAR, KC, BIS, UL, EAC, RoHS, WEEE
Operational conditions
Storage temperature (T-T) -40 - 60 °C
Storage relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 5 - 40 °C
Operating relative humidity (H-H) 25 - 85%
Weight & dimensions
Width 172 mm
Depth 195 mm
Height 165 mm
Weight 1.5 kg
