Newland FM415 Bass Barcode module bar code reader 1D/2D CMOS Black

1D/2D, 640x480 CMOS, LED, USB, 42°H/31.5°W

Key Features

  • 1D & 2D
  • IP54
  • 1.5m drop
  • USB
  • RS232
  • Infrared
  • EasySet
  • LED aimer

Description

The FM415 Bass is designed for fast, straightforward 2D scanning applications. With its intelligent programming, it can be set to read optimally from both close and long distances. Additionally, its power efficiency reduces power consumption and prolongs service life. This stationary scanner is ideal for smoothly transitioning from 1D to 2D scanning without increasing the budget.

Snappy, even in less than perfect conditions
A combination of the IR sensor and the light sensor helps keep workers moving, even in low light conditions. Its strong, white light ensures barcodes are always well lit.

Handsfree or manual scanning
Companies looking for automatic scanning to relieve manual labor can set up the FM415 Bass for hands free scanning. Alternatively, a manual trigger button can be used if preferred.

Intelligent programming
The sensors of the FM415 Bass automatically adjust the brightness of supplementary lighting based on the light that reflects off the barcode. This also makes it an optimal solution for scanning from mobile phone screens. Depending on the application, the scanner can be set to optimally read from close and long distance.

Reliable outdoor use
With an IP rating of 54, this fixed mount scanner can be placed in a housing and used outdoors without worrying about dust or moisture.

Specifications

Scanning
Type Barcode module bar code reader
Linear (1D) barcodes supported AIM-128, Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 Databar Limited, GS1 Databar RSS14, GS1-128 (UCC/EAN-128), ISBN, ISSN, ITF-14, ITF-6, Industrial 25, Interleaved 2 of 5, MSI-Plessey, Matrix 2 of 5, Plessey, Standard 25, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417
Yaw reading angle -60 - 60°
Sensor type CMOS
Scanner type 1D/2D
Pitch reading angle -60 - 60°
Optical sensor resolution (W x H) 640 x 480 pixels
Horizontal field of view 42°
Vertical field of view 31.5°
Ports & interfaces
Connectivity technology Wired
USB 2.0 ports quantity 1
Standard interfaces RS-232, USB
Performance
Protection features Drop resistant
International Protection (IP) code IP54
Product colour Black
Buzzer Yes
Print contrast 25%
Design
Type Barcode module bar code reader
Protection features Drop resistant
International Protection (IP) code IP54
Product colour Black
Power
Power consumption 228 mA
Power source type USB
Weight & dimensions
Width 49 mm
Depth 69 mm
Height 20 mm
Weight 64.6 g
Technical details
Type Barcode module bar code reader
Protection features Drop resistant
USB 2.0 ports quantity 1
International Protection (IP) code IP54
Product colour Black
Buzzer Yes
Compliance certificates CE, Federal Communications Commission (FCC)
Operational conditions
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) -20 - 60 °C
Operating relative humidity (H-H) 5 - 95%
Drop resistance 1.5 m
Other features
USB 2.0 ports quantity 1
