Datalogic

Datalogic PowerScan 9501 Handheld bar code reader 1D/2D Laser Black, Yellow

SKU PBT9501-DPMRB
£782.44
£782.44
Only 9 left

Datalogic

Datalogic PowerScan 9501 Handheld bar code reader 1D/2D Laser Black, Yellow

SKU PBT9501-DPMRB
£782.44
Datalogic PowerScan 9501 Handheld bar code reader 1D/2D Laser Black, Yellow

PowerScan PBT9501, Bluetooth, Fixed Direct Part Marking EVO, Removable Battery

Description

The PowerScan™ 9501 2D area imagers combine omnidirectional reading capabilities with outstanding optical characteristics, resulting in a scanner that is able to read any kind of bar code, regardless of orientation!

The PowerScan family of bar code readers are the ultimate industrial hand held scanners designed and constructed to withstand the toughest environmental conditions.

The PowerScan PD9531 imager is the corded version of the new series. The 9501 cordless area imagers are comprised of the PBT9501 / PM9501 imagers. The PBT9501 features Bluetooth® wireless technology and the PM9501 features Datalogic’s STAR Cordless System™ narrow band radio.

The PowerScan 9501 imagers have an ergonomic shape with well-balanced weight and an intuitive aiming system, allowing the highest first-pass reading rate while reducing unnatural wrist movement. Additionally, the PowerScan 9501 area imagers use a soft-pulsed white illumination light resulting in reduced flashes, which is much gentler on the eyes during scan-intensive operations.

The 9501 area imagers also feature Datalogic’s exclusive 3 Green Lights (3GL™) for superior good-read feedback. The patented ‘Green Spot’ technology directly on the code and dual Good Read LEDs increase visibility at any angle. All models have multi-interface capabilities featuring the most popular interfaces: RS-232, Keyboard Wedge, USB and offer an optional Ethernet for standard or industrial uses.

The PowerScan 9501 imagers introduce a new technology with the ‘Liquid Lens’ feature which increases the depth of field and allows the reading of standard, wide and high density bar codes. Datalogic’s Motionix™ motion-sensing technology detects the natural actions of the operator to automatically switch the scanner into the desired scanning mode (hand held or presentation scanning).

Specifications

Scanning
Type Handheld bar code reader
Linear (1D) barcodes supported GS1 DataBar
2D (matrix & stacked) barcodes supported Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, QR Code
Yaw reading angle -40 - 40°
Working distance 9 cm
Tilt reading angle 0 - 360°
Sensor type Laser
Scanner type 1D/2D
Pitch reading angle -40 - 40°
Light levels (direct sunlight) 0 - 100000 lx
Ports & interfaces
Connectivity technology Wired & Wireless
USB version 2.0
Bluetooth version 3.0
Operating frequency 2400 - 2480 MHz
Standard interfaces Bluetooth, USB
Performance
Protection features Shock resistant
Keys quantity 4 keys
Housing material Plastic
International Protection (IP) code IP65
Product colour Black, Yellow
Certification R.E.A.C.H.
Buzzer Yes
Light levels (direct sunlight) 0 - 100000 lx
Design
Type Handheld bar code reader
Protection features Shock resistant
Keys quantity 4 keys
Housing material Plastic
International Protection (IP) code IP65
Product colour Black, Yellow
Certification R.E.A.C.H.
Power
Power consumption 500 mA
Power source type Battery, DC
Power consumption (typical) 8 W
Battery life 4.5 h
Number of reads per charge 60000
Input voltage 10 V
Battery type Built-in battery
Battery technology Lithium-Ion (Li-Ion)
Battery capacity 3350 mAh
Weight & dimensions
Width 212 mm
Depth 110 mm
Height 74 mm
Weight 380 g
Technical details
Type Handheld bar code reader
Protection features Shock resistant
Keys quantity 4 keys
Housing material Plastic
International Protection (IP) code IP65
Product colour Black, Yellow
Certification R.E.A.C.H.
Buzzer Yes
Harmonized System (HS) code 84716070
Compliance certificates RoHS
Operational conditions
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) -20 - 50 °C
Light levels (direct sunlight) 0 - 100000 lx
Logistics data
Harmonized System (HS) code 84716070
